PRODUCT FEATURES
Higher Durability
The multi-busbar design can decrease the risk of the cell micro- cracks and fingers broken.
High Power Density
High conversion efficiency and more power output per square meter, by lower series resistance and improved light harvesting.
Half-cell Design
Less energy loss cased by shading due to new cell string layout and split J-box, and lower cell connection power loss due to half-cell design.
Bigger Cells with better performance
A slight increase of the size of our cells, Boosts the performance of the newest modules by six percent on average.
ELECTRICAL DATA(STC)
| Module Type | YL365D-34d | YL370D-34d | YL375D-34d | YL380D-34d |
| Rated output(Pmp/Wp) | 365W | 370W | 375W | 380W |
| Short circuit current (Isc) | 11.27A | 11.35A | 11.43A | 11.51A |
| Open circuit voltage(Voc) | 41.05V | 41.25V | 41.45V | 41.65V |
| Maximum power current(Impp) | 10.79A | 10.87A | 10.95A | 11.04A |
| Maximum power voltage(Vmpp) | 33.85V | 34.05V | 34.25V | 34.45V |
| Module efficiency (%) | 20.04% | 20.31% | 20.59% | 20.86% |
| Power tolerance (W) | 0~+5 | 0~+5 | 0~+5 | 0~+5 |
| Standard Test Condition(STC): Irradiance 1000W/m², Cell Tempera ture 25ºC, AM1.5 | ||||
ELECTRICAL DATA(NOCT)
| Module Type | YL365D-34d | YL370D-34d | YL375D-34d | YL348D-34d |
| Rated output(Pmp/Wp) | 270.4W | 274.1W | 277.8W | 281.5W |
| Short circuit current (Isc) | 9.12A | 9.19A | 9.25A | 9.32A |
| Open circuit voltage(Voc) | 38.3V | 38.5V | 38.7V | 38.8V |
| Maximum power current(Impp) | 8.63A | 8.70A | 8.76A | 8.83A |
| Maximum power voltage(Vmpp) | 31.3V | 31.5V | 31.7V | 31.9V |
| Nominal Module Operating Temperature(NOCT): Irradiance 800W/m²,Ambient Temperature 20ºC, AM1.5, Wind Speed 1m/s | ||||
1.Commercial/industrial building roof-top systems
2.Residential roof-top system
3.Solar street lamp
4.Other industrial and commercial applications
5.Rural and island electrification
Material
Project Cases
Factory
Delivery Methods
FAQ.
What's your payment terms?TT,Letter of Credit,Paypal,Western Union etc. Could you send free sample?
Your sample fee will be returned when your place next order.
Can we print our own logo?
Yes absolutely.
What are the advantages of your company?
We are new factory ,now we control thin benifit for developing customers , price ,quality and service will never let customers down!!
